The Printed Circuit Heat Exchanger (PCHE) is a compact and high-performance heat exchanger. It is manufactured by chemically etching microchannels on a metal plate and connecting these channels through diffusion welding into a sturdy core structure. This heat exchanger is specifically designed for extreme working conditions, featuring excellent heat transfer efficiency, extremely high pressure resistance, and outstanding reliability. Moreover, it occupies significantly less space compared to traditional heat exchangers.
Due to its fully welded microchannel design, printed circuit heat exchanger has been widely used in applications involving high-pressure gases, high temperatures, corrosive media, low-temperature processes, and compact energy systems with high requirements. Its typical application fields include hydrogen energy, liquefied natural gas, oil and gas, supercritical carbon dioxide systems, chemical processing, and advanced power generation.
Why PCHE?
Engineered for Extreme Conditions. Built for Reliability.
High Pressure
High Pressure
Built for extreme-pressure gas and supercritical fluid systems.
Extreme Temperatures
Extreme Temperatures
Reliable in both cryogenic and high-temperature environments.
Diffusion-Bonded Core
Diffusion-Bonded Core
Fully welded all-metal structure without gaskets.
Compact Thermal Density
Compact Thermal Density
Cross Section of Flow Channel in PCHE
Engineered at the Microchannel Level
PCHEs achieve exceptional thermal performance through chemically etched microchannels and diffusion-bonded metal core structures.
The microchannel design significantly increases heat transfer density while maintaining compact dimensions, making PCHEs suitable for demanding thermal systems involving high pressure, extreme temperatures, and process-intensive applications.
Unlike conventional heat exchangers, the fully diffusion-bonded all-metal construction provides superior structural integrity and long-term reliability under severe operating conditions.
Engineering & Technical Support
HFM provides engineering-driven support for demanding PCHE projects involving complex thermal conditions and compact process requirements.
Our technical capabilities include thermal design calculation, pressure and temperature evaluation, microchannel configuration optimization, material selection, and custom structural design based on specific operating conditions.
From design verification to manufacturing and testing, HFM focuses on delivering reliable, high-performance PCHE solutions with precision engineering and strict quality control.
